Twist drill dia(mm) | Rated Voltage(v) | Rated Frequency(Hz) | Rated Input Power(w) |
No-load Speed(rpm) |
Max attraction(N) |
Cutting depth(mm) |
Stroke(mm) |
Net/Gross Weight(kgs) | Packing Size(cm) |
|---|---|---|---|---|---|---|---|---|---|---|
| SCY-2300 |
Φ23 |
110/220~ | 50-60 | 1500 | 440 | 14000 | 0-150 | 220 | 25/28 | 46*25*51 |
|
SCY-2300E |
Φ23 | 110/220~ | 50-60 | 1500 | 100-440 | 14000 | 0-150 | 220 | 25/28 | 46*25*51 |
| SCY-2300RE | Φ23 | 110/220~ | 50-60 | 1500 | 100-440 | 14000 | 0-150 | 220 | 25/28 | 46*25*51 |
| SCY-2800 | Φ28 | 110/220~ | 50-60 |
1780 |
340 | 14800 | 0-150 | 230 | 26/29 | 46*25*51 |
| SCY-2800E | Φ28 | 110/220~ | 50-60 | 1780 | 100-340 | 14800 | 0-150 | 230 | 26/29 | 46*25*51 |
| SCY-2800RE | Φ28 | 110/220~ | 50-60 | 1780 | 100-340 | 14800 | 0-150 | 230 | 26/29 | 46*25*51 |
